DST PRAYAS SHALA & MOUSER INNOVATION LAB

All started with a seed of thought, subsequent small steps and a bold decision of establishing Innovation and Entrepreneurship Development Centre (IEDC) for Dayananda Sagar Institutions (DSI) to nurture and promote entrepreneurship among the students and faculty of DSI back in 2009.

The tremendous response by the students, plethora of activities and extensive interaction with communities led to creating an ecosystem conducive to supporting the Startups and Innovators beyond DSI. Additionally, with the financial and other support by NSTEDB, the Department of Science & Technology, Government of India led to the creation of the DERBI Foundation in 2015 with an aim to Fuel Dreams of Innovators, Entrepreneurs and Startups to gather PACE, GALLOP Business and EMERGE successfully through our pre-incubation, incubation, and acceleration programs.

Confocal Laser RAMAN Spectrometer

– Laser wavelength: 785nm (532nm optional),
– Type : Low noise variable power 100mW DPSS Laser,
– Shutter : Solenoid Type,
– Spectrometer Type : Czerny-Turner,
– Focal Length : 200mm,
– Focal Ration : 1/4,
– The spectral resolution : 0.95 cm-1,
– Mapping sample stage : XYMR100 Motorized,
– Travel : 100x100mm,
– Resolution : 0.3125 Micron,
– Scanning Speed: 4mm/sec,
– Confocal Laser RAMAN Spectrometer,
– Model: HO-ED-SP-CRM215,
– Confocal Light collection,
– High lateral spatial resolution,
– Excellent depth Resolution,
– Large collection angle for the Raman light.

Phase Contrast Microscope

– Laser wavelength: 785nm (532nm optional),
– Type : Low noise variable power 100mW DPSS Laser,
– Shutter : Solenoid Type,
– Spectrometer Type : Czerny-Turner,
– Focal Length : 200mm,
– Focal Ration : 1/4,
– The spectral resolution : 0.95 cm-1,
– Mapping sample stage : XYMR100 Motorized,
– Travel : 100x100mm,
– Pixel size – 2.2 um x 2.2um,
– Frame rate – 10 fps @ full resolution,
– Dynamic range – 67.7 dB Signal noise ratio = 38.5 dB,
– Exposure time – 109us to 3000ms,
– Sensitivity 1.76 V/Lux-sec,
– Spectral range = 380nm-650nm.

Fourier Transform Infrared Spectrophotometer-IRSpirit

Flelds Contaminant Analysis Raw materials Identification test Quantitative Analysis Spectral Analysis
Pharmaceuticals and life sciences 0 0 0 0
Chemicals and petroleum 0 0 0
Academia 0 0 0
Pharmaceuticals and life sciences 0 0 0

UV/VIS Spectrophotometer

– Wavelength Range: 250 to 1100nm,
– Resolution : 1 nm,
– Accuracy : ± 1 nm,
– Spectral bandwidth : 2 nm.

Imaging & Optical

– Available Lenses : NA,
– Camera f-number : f/1.5,
– Close–up Lenses/microscopes : NA,
– Field of view : 45*x34*,
– Fixed focus Distance : 70 mm + 10mm,
– Image frequency : 9Hz,
– IR Resolution : 320×240 (76,800 pixels).

Optical Table

Fluke-Prosim 3-4307790 Vital Sign Simulator

The ProSim 3 patient simulators provide the perfect portable vital signs simulator solution for troubleshooting in the field or testing on-the-go. Ideal for ECG, Pacemaker, Arrhythmia and performance testing, Respiration, Invasive blood pressure, Temperature, Cardiac output, Fetal/maternal.

ESA609-12-Electrical Safety Analyzer

CompactDAQ USB Chassis Designed For Small, Portable Sensor Measurement Systems

NI 9401 8-Channel, 100 Ns, TTL Digital Input/Output Module

NI 9207, 16-Ch Voltage/Current, 24-Bit,500 S/S AI Module

PCB Lab Equipment

PCB Prototype Making and Antenna Designing Machine (300W)

Table top SMT Pick and Place Machine

2-in-1 Soldering Adjustable Auxiliary Clip Magnifier with 4- LED Light

150mm Stainless Steel Digital Caliper Vernier with LCD Display Screen

PCB Prototype Making and Antenna Designing Machine (300W)

Table top SMT Pick and Place Machine with Accessories

PCB Prototype Making and Antenna Designing Machine (300W) with Accessories

2-in-1 Soldering Adjustable Auxiliary Clip Magnifier with 4- LED Light

PUHUI T-961 Mini SMT Reflow Oven Infrared IC Heater BGA SMD SMT Rework Station T961 Reflow Wave Oven

PCB Lab Test And Measurement

  • Digital storage oscilloscope: Tektronix- TBS2102B
  • Mixed Signal Oscilloscope: Tektronix- MSO2004B
  • Function Generator
  • Spectrum Analyzer

Mixed Signal Oscilloscope Tektronix- MSO2004B

Digital Oscilloscope Tektronix- TBS2102B

Function Generator Tektronix- AFG1062

Spectrum Analyzer B&K Precision- 2682

Power Supply And Soldering Station

  • Programmable DC power Supply
  • Bench Power supply
  • BGA Rework Station
  • Soldering and De Soldering Machines

Programmable DC Power Supply Keithley- 2230G-60-3

Bench Power Supply

BGA Rework Station Weller-WXD 2010

Soldering and De Soldering Machines

Meters

  • Logic Analyzer
  • Multi Meter
  • LCRQ Meter

Logic Analyzer IKAlogic -SQ200

Multimeter Fluke 115

LCRQ Meter Keysight- U1732C

Stratasys UPrint SE 3D Printer

– uPrint SE 3D printer, – 680-50100 uPrint SE 3D Printer, – Catalyst EX Pre- Processing Software.

3D Scanner

Brand – Artec 3D,
Model – Artec Eva Lite

DIY 3D Printer

  • NI Labview
  • Matlab and Simulink
  • Data science work station

Matlab and Simulink

DELL 5820 data science work station

– Intel Xeon Processor W-2245 (8C, 3.9GHz 4.7GHz Turbo HT 16.5MB,(155W) DDR4-2933),
– Dual NVLink Nvidia Quadro RTX5000, 16GB, 4DP, VirtualLink.

NI Labview

  • Benchtop lathe
  • Bench drill
  • Vacuum Pump
  • Vernier caliper
  • Bench Vice
  • Laser cutter/Engraver
  • Screw gauge
  • Grinders

Bench Drill Clarke CDP5EB

Benchtop Lathe And Accessories Proxxon FD 150/E

Bench grinder-polisher and accessories

Bench Vice Panavise 381
